Single Phase Two Wire Multifunction Din Rail Meter

General Specifications

• Voltage AC (Un): 230V
• Voltage range: 176~276V AC
• Base current (Ib/Iref): 10A
• Max. current (Imax): 100A
• Mini current (Imin): 0.5A
• Starting current: 0.4% of Ib/Iref
• Power consumption: ＜2W/10VA
• Frequency: 50Hz(for MID version) 50/60Hz ± 2% (for non-MID version)
• AC voltage withstand: 4KV for 1 min
• Impulse voltage withstand: 6KV-1.2uS waveform
• Over current withstand: 30Imax for 0.01s
• Pulse 1 output rate: configurable, default 1000i/kWh
• Pulse 2 output rate: non-configurable,1000i/kWh
• Display: LCD with backlit
• Max. reading: 999999.9kWh
