PT-100 temperature to modbus RS485

• Temperature and PT100 resistance values can be read, multi‑functional.
• Up to 247 modules can be cascaded by modifying the 485 address (for more than 16 modules, use R485 Repeaters).
• High quality plastic material manufacturing ensuring maximum durability.
• Temperature measurement range: A version ‑20℃ to +400℃; B Version: ‑20℃ to +220℃. It is recommended to select a small scale version within the measurement range.
• Temperature measurement accuracy is 1%, if the temperature deviation is too large, please recalibrate.

Item Type : Temperature Sensor Module

Function Description of PTA9B01 PT100 RS485 Sensor Module : Supply Voltage: DC 8‑25V(12V is recommended)

Working Current : 8‑13mA

MODBUS RTU protocol, 03 read instruction, 06 write instruction.

Serial Port Baud Rate: 9600 (default), N, 8,1

Up to 247 modules can be cascaded by modifying the 485 address (please use R485 Repeaters for more than 16)

Temperature and PT100 resistance values can be read

Adaptive Sensor: PT100 3‑wire or 2‑wire sensor

Temperature Measurement Range :

A version ‑20℃ to +400℃

B Version: ‑20℃ to +220℃

It is recommended to select a small scale version within the measurement range.

Temperature measurement accuracy: 1%, if the temperature deviation is too large, please recalibrate

Material : plastic

color : As shown

Package Contents : 1 x Platinum Thermal Resistance Sensor
